1. Where can the water separator be used?
On every type of equipment or device that uses compressed air.
2. What kind of equipment is the water separator used with?
It is used in a wide variety of applications including production facilities, processing facilities, and with medical equipment.
3. What is method used by BOD water separator?
It uses a revolutionary technology Cyclone method + Collision Separation Method.
4. How does the collision separation system separates moisture from the air?
It uses a proprietary method that combines collision separation and centrifugal force to take advantage of differences in specific gravity.
5. Although we control the dew point, some moisture still forms.
Install BOD water separator just before each working device and you can remove any moisture that has built up.
6. Although we are using a moisture-removing device, some water is still present. Why?
Dew will form in any long pipe between a compressor dryer and an end device.
7. Can the water separator remove dust?
Although BOD water separator is not designed to remove dust, it can remove dust that is 5um or larger in size.
8. Can the water separator remove oil?
Although BOD water separator is not designed specifically to remove oil, it can remove liquid oil.
9. What material is used to make the water separator?
The body of BOD water separator is die-cast aluminum.
10. Where should the water separator be installed?
Install BOD water separator just before each end unit, not in a compressor room.
11. Can I install the water separator horizontally?
No, please make sure to install it vertically.
12. Is it possible for water droplets to form in a pipe after the water separator?
It may be possible due to differences in temperature between the atmosphere and inside the pipe. Installing thermal insulation on a pipe is effective in preventing the formation of water droplets.
13. Are specialized installation brackets available?
Yes. Installation brackets are available as an option.
14. How much maintenance is needed after the water separator installed?
There is no need for maintenance. Bod water separator has no running costs and needs no handling after it is installed.
15. Is there a filter that should be replaced?
No, there is no filter and no parts need to be replaced.
16. What is the warranty time of BOD water separator?
It's one year.We will send a new one to you free of charge to replace the faulty one within warranty period.
